Canterbury

Luxury Widebeam Canal Boat

The renowned Aqualine quality is once again evident in the Canterbury widebeam canal boat. A truly luxurious craft with an impressive level of equipment as standard, this boat offers exceptional value for money.

The real attraction lies in the modular design which allows the layout to be altered to customise your boat and choose the length, up to 70ft and beam up to 12ft.

Canterbury Widebeam Boat Builder - Hydraulic Steering
Canterbury 12ft Widebeam Boat Builder - Galley
12ft Canterbury Widebeam - Saloon
Widebeam Boat Builder - Canterbury Galley Cupboard
Luxury Widebeam - Canterbury Gas Hob
Canterbury Widebeam - Galley and Dining Area
Canterbury Widebeam Multi Fuel Stove
Canterbury Widebeam - Woodwork Detail
Canterbury Widebeam - Fin Rads
Canterbury Widebeam - Corridor Desk Area
Canterbury 12ft Widebeam - Corridor Storage
Canterbury 12ft Widebeam Boat Builder - Second Cabin
Canterbury - Widebeam - Second Bedroom
Canterbury Widebeam - Bathroom 2
Canterbury Widebeam - Bathroom
Canterbury Widebeam - Bedroom Storage
Luxury 12ft Widebeam Boat Builder - Canterbury Bedroom 2
Luxury 12ft Widebeam Boat Builder - Canterbury Bedroom
12ft Canterbury Widebeam - Reverse Layout Bedroom
Canterbury Widebeam - Enclosed Stern Seating
Luxury Canterbury Widebeam - Dining Area Stern
Canterbury 12ft Widebeam Boat Builder - Hydraulic Steering
Canterbury Widebeam - External Paint
Canterbury Widebeam - Enclosed Stern & Pram Hood
Canterbury Widebeam Bow

Aqualine Canterbury from £107,958 exc vat

Above: Canterbury 10ft & 12ft beam typical floor plans.
If you would like to tailor your vessel to meet you exact requirements we are more than happy to discuss your requirements.

Aqualine’s hand crafted boats offer bespoke level design and finish at an affordable price, backed by a reassuring after sales support service.

All boats conform to the Recreational Craft Directive (RCD) and come complete with CE mark plus a full 12 month warranty, and extended warranties on many parts. A full owner’s manual with operating instructions and technical information is also provided.

Layout
The modular design approach means that rooms can be re-arranged to have the bedroom at the bow rather than at the stern or to include a second bedroom, whilst the length can be extended in one foot increments up to 70 feet to to extend existing rooms and to a maximum of 12ft on the beam (wider on request).

Lining & Wood Type
All boats come with a choice of Ash or Oak. The roof in the standard craft is solid hardwood linear tongue and groove. The bedroom and bathroom have diagonal tongue and groove on the cabin sides. the remaining cabin area (galley, saloon) has a paneled effect, lined with deep hardwood trim. Full paneling or full tongue and groove also available.

Flooring
The bedroom area is carpeted (with underlay) and the bathroom floor is tiled, whilst the remainder of the boat has solid 20mm hardwood flooring fitted over a plywood sub floor. Full hardwood, carpet or galley tiling available at no extra cost.

Interior Finishes
We offer a choice of colours on soft furnishings, tiles, carpets (with underlay) and work surfaces as well as the exterior paintwork.

Bedroom
Fixed queen sized double bed with drawers under, overhead cupboards with down lights and a cupboard with a drawer at either side. Full length wardrobes provide that all important hanging space.

Second Cabin (Optional)
Complete with a single berth and a workstation area to make this a practical, multi-use room. A second single bunk bed can be provided which also folds down in the daytime to make the bed into a sofa/seating area. Alternatively an extendable double bed can be fitted instead to make it a comfortable guest room. This bedroom can also be omitted giving more space in the saloon if preferred.

Bathroom
An electronic macerator (pump out) toilet, vanity unit with hand basin and full wall mirror with illuminated pelmet over. There is a shower wall, full sized corner shower with a mixer unit. The shower is surrounded by a chrome quadrant screen. There is a heated towel rail, and shelving to provide further storage. A bath with shower over is available as an option, not to mention a choice of shower panel colours.

Galley
Either a split or U-shaped galley is available, both with solid hardwood doors and granite work surfaces. There is a full sized stainless steel hob and double oven, integrated fridge and deep full size stainless steel sink with monobloc taps over. The use of ‘magic corners’ provides an ingenious solution to the problem of hard to reach corners. Overhead cupboards and shelving provide further storage. Stainless steel extractor fan.

Saloon
Large saloon perfect for free standing furniture with a cast iron solid fuel stove. Depending on your layout there is a choice of various units to provide ample storage as well as to house the built-in 32″ HD ready digital flat screen TV and DVD. There is also the opportunity to have a dining option included in the saloon, providing table and chairs for four, which is cleverly concealed under the gunwale when not in use.
TV cinema surround sound upgrade brings the movies to your boat with a multi purpose Blu-ray Sound bar with hidden sub woofer, 2.1 surround sound, USB connector for MP3 docking etc. and a built in radio. Perfect whatever the occasion.

Under gunwale & step lighting
Down lighting brings ambient and soft lighting in the bedroom and corridor. Bow and stern step lighting combines safety and style.

Paint Scheme
We offer a range of designs and paint combinations (2 colour paint and coachline as standard) using a two part polyurethane paint. All decks, roof and gunwales are treated to give a non-slip finish.
Add that extra touch of style and individuality and make sure your boat is the envy of the waterways by adding an extra colour – choose and additional colour for the roof, handrails, counterbands and painted panels or maybe all three!

Cruising Pack
Front, rear and 6 side fenders, landline for connecting to shore power, mallet, 2 mooring pins, tiller and pin, windlass, lifebuoy, front and rear ropes, chimney and chinese hat, fire extinguishers, fire blanket, smoke and CO alarm.


Item Description
Length: Lengths from 57ft up to 70ft available)
Width: 12ft
Stern Type: Cruiser
Engine: 4 Cylinder 2190cc Barrus Yanmar Shire 50hp (4 Cylinder 3319cc 70hp upgrade available)
Gearbox: PRM 150 Hydraulic Gearbox (PRM 260 D2 upgrade available)
Engine Battery Alternator: 50A
Leisure Battery Alternator: 240A
Diesel Tank Capacity: 95 Gallons
Water Tank Construction: Stainless steel
Water Tank Capacity: 170 Gallons
Hull Protection: Bitumen (2 Pack upgrade available)
Windows: Mixture of 18" port holes & 36" rectangular windows (size changes accommodated)
Decks: All self draining
Weed Hatch: Quick release
Fender Eyes: Brass recessed (chrome option available)
Gas Locker: To hold 2 x 13kg bottles (1 provided)
Rubbing Strakes: 2 full length (3 at bow & stern)
Handrails: T-Section easy grip with scruppers for drainage
Bow Lockers: Fitted as standard
Anodes: 4 x 2.5kg magnesium anodes
Stern Doors: Steel Lockable
Bow Doors: Hardwood, glazed and lockable


Item Description
Shoreline Connection: Yes
Leisure Battery Bank: 4 x 110A semi-traction batteries (optional gel tubular 600A battery upgrade)
Leisure Battery Bank Voltage: 12v
Inverter Type: Victron Pure Sine Wave - Combi Charger 70A
Inverter Capacity: 1600W
Galvanic Isolator: Yes
Engine Gauges: Revs, temperature & oil warning lights (deluxe control panel available including tachometer, oil pressure, voltmeter & water temperature)
Quantity Electrical Sockets: 6 brushed stainless steel double sockets (option for additional)
TV Signal Type: Digital (Satellite upgrade available)
TV Points: Qty. 1 (option for additional)
Appliances: Full sized stainless steel hob, double oven, integrated fridge, stainless steel extractor


Item Description
Solid Fuel Stove: Morso Solid Fuel Stove
Central Heating: Diesel Fired Heating
Radiators: Finrads in galley and saloon - heated towel rail in bathroom - Radiator in bedroom
Calorifier (Hot Water Tank): 60 litres, twin coil & immersion
Bath/Shower Type: Shower
Toilet Type: Macerator (pump-out)
Toilet Tank Capacity: 47 Gallons
+ Overview

Aqualine’s hand crafted boats offer bespoke level design and finish at an affordable price, backed by a reassuring after sales support service.

All boats conform to the Recreational Craft Directive (RCD) and come complete with CE mark plus a full 12 month warranty, and extended warranties on many parts. A full owner’s manual with operating instructions and technical information is also provided.

Layout
The modular design approach means that rooms can be re-arranged to have the bedroom at the bow rather than at the stern or to include a second bedroom, whilst the length can be extended in one foot increments up to 70 feet to to extend existing rooms and to a maximum of 12ft on the beam (wider on request).

Lining & Wood Type
All boats come with a choice of Ash or Oak. The roof in the standard craft is solid hardwood linear tongue and groove. The bedroom and bathroom have diagonal tongue and groove on the cabin sides. the remaining cabin area (galley, saloon) has a paneled effect, lined with deep hardwood trim. Full paneling or full tongue and groove also available.

Flooring
The bedroom area is carpeted (with underlay) and the bathroom floor is tiled, whilst the remainder of the boat has solid 20mm hardwood flooring fitted over a plywood sub floor. Full hardwood, carpet or galley tiling available at no extra cost.

Interior Finishes
We offer a choice of colours on soft furnishings, tiles, carpets (with underlay) and work surfaces as well as the exterior paintwork.

Bedroom
Fixed queen sized double bed with drawers under, overhead cupboards with down lights and a cupboard with a drawer at either side. Full length wardrobes provide that all important hanging space.

Second Cabin (Optional)
Complete with a single berth and a workstation area to make this a practical, multi-use room. A second single bunk bed can be provided which also folds down in the daytime to make the bed into a sofa/seating area. Alternatively an extendable double bed can be fitted instead to make it a comfortable guest room. This bedroom can also be omitted giving more space in the saloon if preferred.

Bathroom
An electronic macerator (pump out) toilet, vanity unit with hand basin and full wall mirror with illuminated pelmet over. There is a shower wall, full sized corner shower with a mixer unit. The shower is surrounded by a chrome quadrant screen. There is a heated towel rail, and shelving to provide further storage. A bath with shower over is available as an option, not to mention a choice of shower panel colours.

Galley
Either a split or U-shaped galley is available, both with solid hardwood doors and granite work surfaces. There is a full sized stainless steel hob and double oven, integrated fridge and deep full size stainless steel sink with monobloc taps over. The use of ‘magic corners’ provides an ingenious solution to the problem of hard to reach corners. Overhead cupboards and shelving provide further storage. Stainless steel extractor fan.

Saloon
Large saloon perfect for free standing furniture with a cast iron solid fuel stove. Depending on your layout there is a choice of various units to provide ample storage as well as to house the built-in 32″ HD ready digital flat screen TV and DVD. There is also the opportunity to have a dining option included in the saloon, providing table and chairs for four, which is cleverly concealed under the gunwale when not in use.
TV cinema surround sound upgrade brings the movies to your boat with a multi purpose Blu-ray Sound bar with hidden sub woofer, 2.1 surround sound, USB connector for MP3 docking etc. and a built in radio. Perfect whatever the occasion.

Under gunwale & step lighting
Down lighting brings ambient and soft lighting in the bedroom and corridor. Bow and stern step lighting combines safety and style.

Paint Scheme
We offer a range of designs and paint combinations (2 colour paint and coachline as standard) using a two part polyurethane paint. All decks, roof and gunwales are treated to give a non-slip finish.
Add that extra touch of style and individuality and make sure your boat is the envy of the waterways by adding an extra colour – choose and additional colour for the roof, handrails, counterbands and painted panels or maybe all three!

Cruising Pack
Front, rear and 6 side fenders, landline for connecting to shore power, mallet, 2 mooring pins, tiller and pin, windlass, lifebuoy, front and rear ropes, chimney and chinese hat, fire extinguishers, fire blanket, smoke and CO alarm.

+ Picture Gallery
+ Hull & Integral Parts


Item Description
Length: Lengths from 57ft up to 70ft available)
Width: 12ft
Stern Type: Cruiser
Engine: 4 Cylinder 2190cc Barrus Yanmar Shire 50hp (4 Cylinder 3319cc 70hp upgrade available)
Gearbox: PRM 150 Hydraulic Gearbox (PRM 260 D2 upgrade available)
Engine Battery Alternator: 50A
Leisure Battery Alternator: 240A
Diesel Tank Capacity: 95 Gallons
Water Tank Construction: Stainless steel
Water Tank Capacity: 170 Gallons
Hull Protection: Bitumen (2 Pack upgrade available)
Windows: Mixture of 18" port holes & 36" rectangular windows (size changes accommodated)
Decks: All self draining
Weed Hatch: Quick release
Fender Eyes: Brass recessed (chrome option available)
Gas Locker: To hold 2 x 13kg bottles (1 provided)
Rubbing Strakes: 2 full length (3 at bow & stern)
Handrails: T-Section easy grip with scruppers for drainage
Bow Lockers: Fitted as standard
Anodes: 4 x 2.5kg magnesium anodes
Stern Doors: Steel Lockable
Bow Doors: Hardwood, glazed and lockable
+ Electrics


Item Description
Shoreline Connection: Yes
Leisure Battery Bank: 4 x 110A semi-traction batteries (optional gel tubular 600A battery upgrade)
Leisure Battery Bank Voltage: 12v
Inverter Type: Victron Pure Sine Wave - Combi Charger 70A
Inverter Capacity: 1600W
Galvanic Isolator: Yes
Engine Gauges: Revs, temperature & oil warning lights (deluxe control panel available including tachometer, oil pressure, voltmeter & water temperature)
Quantity Electrical Sockets: 6 brushed stainless steel double sockets (option for additional)
TV Signal Type: Digital (Satellite upgrade available)
TV Points: Qty. 1 (option for additional)
Appliances: Full sized stainless steel hob, double oven, integrated fridge, stainless steel extractor
+ Heating & Plumbing


Item Description
Solid Fuel Stove: Morso Solid Fuel Stove
Central Heating: Diesel Fired Heating
Radiators: Finrads in galley and saloon - heated towel rail in bathroom - Radiator in bedroom
Calorifier (Hot Water Tank): 60 litres, twin coil & immersion
Bath/Shower Type: Shower
Toilet Type: Macerator (pump-out)
Toilet Tank Capacity: 47 Gallons
