Narrowboat Range

Luxurious Narrowboats

Aqualine’s hand-crafted narrowboats offer bespoke level design and finish at affordable price, backed by a reassuring after-sales support service.

Choose from four layouts, which can all be personalised with a wide choice of finishes and optional extras. You can also choose your length up to 70ft to incorporate more rooms or give more space to existing rooms.

img_5575
img_5584
img_5587
img_5576
img_5594
img_5591
img_5598
img_5602
img_5604
img_5608
img_5607

Aqualine Madison from £99,950 inc vat

Above: Aqualine Narrowboats – typical floor plans.
If you would like to tailor your vessel to meet you exact requirements we are more than happy to discuss your requirements.

Aqualine’s hand-crafted narrowboats offer bespoke level design and finish at affordable price, backed by a reassuring after-sales support service.

All boats conform to the Recreational Craft Directive and come complete with CE mark plus a full 12 month warranty, and extended warranties on many parts. A full owner’s manual with operating instructions and technical information is also provided.

Choose from four layouts known as the Madison, Monaco, Manhattan & Montana which can all be personalised with a wide choice of finishes and optional extras. You can also choose your length up to 70ft to incorporate more rooms or give more space to existing rooms.

Lining and Wood Type
All boats come with a choice of Ash or Oak. The roof in the standard craft is solid hardwood linear tongue and groove. The bedroom and bathroom have diagonal tongue and groove on the cabin sides. The remaining cabin area (galley, saloon) has a panelled effect, lined with deep hardwood trim, Full panelling or full tongue and groove also available.

Flooring
The bedroom area is carpeted (with underlay) and the bathroom floor is tiled, whilst the remainder of the boat has solid 20mm hardwood flooring fitted over a plywood sub floor. Full hardwood, carpet or galley tiling is available at no extra cost.

Interior Finishes
We offer a choice of colours on soft furnishings, tiles, carpets (with underlay) and work surfaces as well as exterior paintwork.

Bedroom
Fixed double bed (option to have a king-size extending bed) with drawers under and overhead cupboard with down lights. Full length wardrobes. The Madison boasts an additional vanity unit.
Fancy extra sleeping space but don’t want a bigger boat?
Why not fit a dinette in the salon and have an extra two berth sleeping area for guests, or extend the length of the boat to incorporate a separate dinette cabin.

Bathroom
An electric macerator (pump out) toilet, vanity unit with hand basin and full wall mirror with illuminated pelmet over. There is a full-sized corner shower with a mixer unit. The shower is surrounded by a hardwood glazed screen and door. There is a heated towel rail, and shelving to provide further storage. The Madison and Manhattan bathrooms are compartmentalised whilst the Monaco is a full-width walk through bathroom.

Galley
Split galley with solid hardwood doors and hardwood or granite work surfaces and optional breakfast bar or dinette. There is a full-sized stainless steel hob, oven and separate grill, integrated fridge and deep stainless steel sink with monobloc taps over. The use of ‘magic corners’ provides an ingenious solutions to the problem of hard to reach corners. Overhead cupboards and shelving provides further storage. The Monaco has a U-shaped galley.

Saloon
Large saloon designed for free standing furniture with a cast iron solid fuel stove. We fit a TV aerial and a unit with shelving, or why not upgrade to the TV/DVD option which fits discretely under the gunwhale.
TV cinema surround sound upgrade?
Bring the movies to your boat with a multi-purpose Blu-ray sound bar with a hidden sub-woofer, 2.1 surround sound, USB connector for MP3 docking etc. and a built in radio. Perfect whatever the occasion.

Utility/Second Toilet
The utility area is fitted as standard on a Monaco design, which can be utilised for optional second toilet. Using our bespoke length service you can of course incorporate this in to other designs.

Lighting

  1. Under Gunwale Lighting
  2. Downlighting brings ambient and soft lighting in the bedroom and corridor.
  3. Step Lights – Bow and Stern

Heating System
Diesel fired central heating system with timer which runs the finrads and a heated towel rail in the bathroom, also provides hot water through a twin coil calorifier, with immersion. The calorifier is also connected to the engine cooling circuit meaning that the engine will heat the hot water.

240v Power System
Power to 4 brushed stainless steel double sockets (plus a plastic socket concealed inside the TV unit) is supplied via a 240V system fitted as standard. Tested and installed to RCD standard for connecting to shore power when moored in a marina. When cruising, power is supplied from a Victron 1200 Inverter with 50 amp charger. 3000 inverter with 120 amp charger is available as an upgrade.

12v System
4 x 110 amp semi-traction domestic batteries, which are charged by a dedicated alternator. These are connected to a purpose-built distribution panel, and the system has circuit breakers for all of the appliances. The lighting is a combination of wall lights and LED down lighters throughout the boat. There is also under gunwale lighting in the corridor, and step lights at the bow and stern.

Bigger capacity and more robust batteries …
Upgrade to gel tubular batteries with a storage capacity of 600 amh (amp hours) which are designed to accommodate regular charging and discharging.

Engines
E.P Barrus Yanmar engine 38hp 4 cylinder, Newage PRM 120 gearbox, 1 x 50amp and 1 x 110amp alternators, standard panel, with a 5 year warranty.

Choosing a boat 60 feet or over or plan on cruising rivers?
Upgrade: E.P Barrus Yanmar engine: 4 cylinder, 45hp engine with a 50 and a 240 amp alternator. Keel cooled, indirect injection. PRM 150 hydraulic gearbox. Standard control panel. Upgraded control panel is available which features tachometer, oil pressure and water temperature gauges.

(All engines come installed, tested and running with one starter battery and a water lubricated stern tube).

Steelwork
Enhanced hull design built to CBA Code of Practice guidelines, with two full-length rubbing strakes. The hull is blacked (blacking not suitable for salt/brackish water).

Cruising Pack
Front, rear and 6 side fenders, landline for connecting to shore power, mallet, 2 mooring pins, tiller & pin, windlass, lifebuoy, front & rear ropes, chimney & chinese hat, fire extinguishers, fire blanket, smoke and CO alarm.

Paint Scheme
We offer a range of designs and paint combinations (single colour paint and coachline as standard). All decks, roof and gunwales are finished with a non-slip surface.

Add that extra touch of style and individuality …..

Make sure your boat is the envy of the waterways by adding an extra colour. Choose an additional colour for the roof, handrails, couterbands and painted panels or maybe all four.

Window Sizes
A mixture of portholes and windows (and a set of side doors) is used in the boat – refer to individual layout diagrams. Changes to window sizes can be accommodated and we offer a choice between windows and portholes or a combination of both.

Bow Lockers
Offer additional seating and handy storage for mooring pins, spare ropes and hose pipes.

Side Doors
Allows extra light and ventilation to flood in as and when you choose.


Item Description
Length: From 57ft - 70ft
Width: 6ft 10"
Stern Type: Cruiser as standard (Trad & Semi-Trad Options)
Engine: E.P Barrus Yanmar engine 38hp 4 cylinder (45hp upgrade available)
Gearbox: Newage PRM 120 gearbox,
Engine Battery Alternator: 50A
Leisure Battery Alternator: 110A
Diesel Tank Capacity: Approx 55 gallons
Water Tank Construction: Stainless steel
Water Tank Capacity: Approx 110 gallons
Hull Protection: Bitumen (2 Pack upgrade available)
Windows: Mixture of 18" port holes 36" & 42" rectangular windows (size changes accommodated)
Decks: All self draining
Weed Hatch: Quick release
Fender Eyes: Brass recessed (chrome option available)
Gas Locker: To hold 2 x 13kg bottles (1 provided)
Rubbing Strakes: 2 full length (3 at bow & stern)
Handrails: T-Section easy grip with scruppers for drainage
Bow Lockers: Fitted as standard
Anodes: 4 x 2.5kg magnesium anodes
Stern Doors: Steel Lockable
Bow Doors: Hardwood, glazed and lockable


Item Description
Shoreline Connection: Yes
Leisure Battery Bank: 4 x 110A semi-traction batteries (optional gel tubular 600A battery upgrade)
Leisure Battery Bank Voltage: 12v
Inverter Type: Victron Pure Sine Wave - Combi Charger 50A
Inverter Capacity: 1200W
Galvanic Isolator: Yes
Engine Gauges: Revs, temperature & oil warning lights (deluxe control panel available including tachometer, oil pressure, voltmeter & water temperature)
Quantity Electrical Sockets: 6 brushed stainless steel double sockets (option for additional)
TV Signal Type: Digital (Satellite upgrade available)
TV Points: Qty. 1 (option for additional)
Appliances: Full sized stainless steel hob, oven & separate grill, integrated fridge


Item Description
Solid Fuel Stove: Morso solid fuel stove
Central Heating: Diesel fired heating system
Radiators: Finrads - heated towel rail in bathroom
Calorifier (Hot Water Tank): 60 litres approx. twin coil & immersion
Bath/Shower Type: Shower
Toilet Type: Macerator (pump-out)
Toilet Tank Capacity: 47 Gallons
